TB Rapid Test Cassette

TB Rapid Test Cassette

TB Rapid Test Cassette
TB Rapid Test Cassette

Large Image :  TB Rapid Test Cassette Get Best Price

Product Details:
Place of Origin: CHINA
Brand Name: SPAN
Certification: TB
Model Number: TB
Payment & Shipping Terms:
Minimum Order Quantity: 100 TESTS
Price: Negotibale
Packaging Details: 40 tests/box
Delivery Time: within 3-5 working days(depends on your quantity)
Payment Terms: T/T, Western Union,Paypal
Supply Ability: TB
Detailed Product Description

TB Rapid Test Cassette


For the qualitative detection of Antibody against Tuberculosis in serum and plasma



The TB Rapid Test is a chromatographic immunoassay for direct qualitative detection of Tuberculosis antibody in human serum or plasma.



Tuberculosis remains an important socio-economical and medical problem throughout the world. According to the Centers for Disease Control, the incidence of TB is expected to increase from 7.5 million cases per year in 1995 to 11.9 million in 2005. The case fatality rate is estimated at 55% for untreated people and 15% for the treated patients.

The commonly used diagnostic tests for the tuberculosis such as sputum examination of acid fast bascilli, culture of sputum or other fluids, the tuberculin skin test and radiological investigations do not achieve the required diagnostic sensitivity.

TB is a chromatographic immunoassay test for the detection of TB antibody in human serum or plasma. Specific antigens are pre-coated onto membrane as a capture reagent on the test region. During the test, specimen is allowed to react with the antigens firstly. The chasing buffer mixed with specific Mouse anti human antibody, which is conjugated with colloidal gold, will flow up the membrane. If TB antibody is present, a pink colored band will develop on the test region of membrane. Absence of this pink colored band in the test region suggests a negative result. To serve as a procedural control, a pink colored band in the C region will always appear regardless of the presence or absence of TB antibody.



1. One pouched cassette with desiccant.

2. Blood diluent in a dropper bottle, stored at 2-8°C.

3. One piece of operating instruction



  1. For in vitro diagnostic use only.
  2. All patient samples should be treated as if capable of transmitting diseases.
  3. Do not interchange reagents from different lots or use the test kit beyond expiration date.
  4. Icteric, lipemic, hemolysed, heat treated and contaminated sera may give erroneous results.



The kits should be stored at temperature 4-30°C, the sealed pouch for the duration of the shelf life (24 months).




  1. Have a certified phlebotomist collect whole blood into a purple, blue or green top collection tube (containing EDTA, citrate or heparin, respectively) by vein puncture.
  2. Separate the plasma by centrifugation.
  3. Carefully withdraw the plasma for testing, or label and store it at 2-8°C for up to two weeks. Plasma may be frozen at -20°C for up to one year.


  1. Have a certified phlebotomist collect whole blood into a red top collection tube (containing no anticoagulants) by veinpuncture.
  2. Allow the blood to clot.
  3. Separate the serum by centrifugation.
  4. Carefully withdraw the serum for testing or label and store it at 2-8°C for up o two weeks. Serum may be frozen at -20°C for up to one year.



  1. Bring all reagent to room temperature.
  2. Open a pouch containing a cassette and lay the cassette on a flat surface.
  3. Carefully apply 3ml of sample Into the sample well(please the picture)
  4. Then add 2 drops (80ul) of buffer into the buffer well (B).
  5. Read the result within or up to 15 minutes. Dispose of the cassette after 20 minutes.
